Wire stripping crimping machine
Function:
Wire cut off at both ends, single head pressing, single head on tin, twisted wire terminal direction, good product/bad identification, visual identification of how much plastic bag, leak test, pressure test, terminal width 1-7 wire color length select.
Specifications:
| Capacity | Single head pressed on tin insert 1.6 seconds/bar (100MM cut off long time) 2200PCS/hour |
| Wire range | OD: 0.8-2.0MM 28#-20# |
| Wire cut length | 40MM-2000MM |
| Stripping length | 0.5MM-10MM |
| Crimp capacity: 2T | air pressure alarm, rubber in and out, missing, insertion detection, terminal presence, visual computer device |
| Detection device | air pressure alarm, rubber in and out,missing, insertion detection, terminal presence, visual computer device |
| Power Supply | AC220V/110V 50/60HZ |
| Pressure | 0.5MPA-0.7MPA |
| Equipment size | 1500*1200*1650mm |
