Semi-auto SMT Line
Features:
Solder Paste Mixer:
1.Okay for all brands of 500g paste, mixing with 2 cans in one time, which can save time and efficient
2.Applies to Omron time relay controller, reliable and easy to operate
3.Speed can adjust.
Solder Paste Printer:
1.Applies to Korean guide rail,printing precise is up to 0.2mm IC
2.PLC + touch screen display, more stable and easy to operate.
3.Suitable for long LED PCB , such as 600mm/1200mm/1500mm length PCB(make to order).
PCB Conveyor:
1.Precise M-screw,manual guide rail width adjustable,which ensures two guide rails move smoothly.
2.Imported round special belt, and the patent tracks ,decrease the PCB drop problem.
3.Stucture is made by the aluminum alloy,more stable and longer lifespan.
4.With SMEMA.
Pick and Place Machine:
1.SMT specifications: platform 600X400mm, applicable to the current market of 99% LED products;PCB board can be affixed to various shapes, without clamps.
2.Mount: Mount 0603 to 7272 can meet all specifications of SMD LED components. In addition to all the planar LED plane, other electronic components (such as resistors,capacitors) and high power LED and the lens can be produced;.
3.High precision: X, Y, W axis are equipped with precision ball screw and guide rail, Z axis 6 sets of imported motor drive,enhance the smooth coordination ofequipment movement, reduce abnormal noise, greatly improve the accuracy and speed of the patch.
Reflow Oven:
1.Lenovo PC , windows 7 operation system, Chinese-English interface screen.
2.15% heat transferring efficiency was improved ,which is more suitable for the LEAD-FREE welding process.
3.Siemens PLC control, more durable and stable.
PCB Magazine Unloader:
1.Applies to the PLC+touch screen controller.
2.Special gas circuit design to ensure no PCB breakage.
3.It can hold 1magazine, small footprint.
4.With SMEMA signal.
Specifications:
Solder Paste Mixer | Dimensions | 430×400×480（mm) | Revolution speed | 600RPM/Min |
Rotation speed | 350RPM/Min | Power | AC110/220V 50/60HZ | |
Mixing method | Centrifugal mixing | Mixing angle | 45° | |
Solder Paste Printer | Dimensions | 850*670*1550(mm) | Platform size | 320*400(mm) |
PCB size | 300*400(mm) | Stencil size | 550*680(mm) | |
Printing speed | 0~8000(mm)/Min | PCB tuning range | Front/Side + 10mm | |
PCB Conveyor | Dimensions(mm) | Length×640×910 | PCB Width | 50-350(mm) |
PCB Direction | L-R or R-L | Speed | 0-1000(mm)/Min | |
Communication Plug | SMEMA Signal | Platform Material | ESD Rubber Mat | |
Pick and Place Machine | Maximum PCB area | 600×400mm | Mounting head | 8 Heads |
Max placement speed | 40000CPH | Movement precision | ±0.05mm | |
Minimum component | 0402-14MM | Operating system | WINDOWS 7 | |
PCB Magazine Unloader | Dimensions | 850*765*1250mm | PCB size | 50*50-330*250mm |
Magazine size | 355*320*563mm | Magazine quantity | 1 | |
Air pressure | 4-6bar,10L/min max | Weight | Approx.120Kgs | |
Reflow Oven | Heating zones | Top8 /bottom8 | Max width of PCB | 400mm |
Width of conveyor | 50~400mm | Conveyor speed | 0～2000mm/Min | |
Heating time | Approx. 20min | Dimensions(mm) | 5400*1370*1555 | |
More details of the product,please check it.
Semi-auto Solder Paste Printer
If you are interested about it,please contact us.
