Electrical cable stripping machine

Model: OB-WS030
Brand: OUBEL
Delivery Time: 3-5 working days

Compare

描述

Electrical cable stripping machine

Features:

1. This machine is a new type of cable processing equipment controlled by microcomputer, mainly for the automotive industry, power cable, power cable industry, electric control cabinet, battery box cable, new energy vehicle wiring harness, charging pile harness, charging gun Harness, BV hard wire, BVR soft wire, can handle the entire length of the wire as needed, total length, head stripping and tail stripping, thus greatly improving efficiency;

2. Automatic tangential cutting, stripping the insulation at both ends, can carry out multi-level stripping processing at the same time

3. Industrial grade control chip with high precision motor and driver, making the machine stable and high speed for long hours of work;

4. Using controller control, touch screen operation mode, can save 100 sets of stripping procedures;

5. 70 square meters of cable can be easily processed, and strong power is the guarantee for improving the efficiency of work;

6. The function of this machine is strong, and multiple ports are reserved for the input and output signals of some auxiliary equipments;

7. Auxiliary equipment: automatic wire feeder, receiver, robot, winding machine, etc.

Specifications:

Display mode7 inch real color touch screen
functionWire, electric cable wire stripping cutting
Head strippingRV cable is fully off MAX 120mm., Sheath wire full stripping Max 500MM
Tail strippingthe cable, MAX 260mm
Cable typescable, PVC,..Etc.
Stripping size10-70 mm2
Cutting length0.1-99999.9mm
Cutting toleranceWithin 0.002*L(L=cutting length)
 Max dia of pipe Φ25
Material of bladesimported high speed steel.
Productivity (time/hour)1800 PCS/h
Driving mode32 wheel drive (silent hybrid stepping motor, servo tool holder)
Feeding methodFeeding with belt,the cable has no indentation.
Remark the special cable can be customized, the sample line test should be sent
